Specifications

Product: Solis Hub

Dimensions: 185*130*30mm(L*W*H) (Excluding Antennas)
Weight: 836g without packaging, 1127g with packaging
Case: Aluminum Alloy Exterior - Black
CPU: RTL8197FH-VG5-CG, Single Core 1.0GHz
Module: SIM6600 M.2 / SIM6600 eM.2
Memory / Storage: DDR2 128 MB / 16 MB SPI NOR Flash
SIM card slot: Micro SIM card / vSIM
LEDs: Power Indicator / VS (vSIM) Indicator / LTE Indicator / 2.4GHz WiFi / 5GHz WiFi / WPS Indicator / Signal LED (3 LED) / WAN Indicator / LAN Indicators
Reset Button: Reset/WPS
Power Port 12V 1.5A DC
Power Adapter: Input: 100-240V 0.7A max | Output: 12.0V 1.5A
Temperature: Working: 0°C~40°C | Storage: -30°C ~ 70°C
Humidity 5%~90%, non-condensing
Cellular Specifications
4G Bands:  B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28A/B28B/B29/B30/B34/B38/B39/B40/B41/B66/B71
3G Bands: B1/B2/B4/B5/B8
LTE CA: 1+1; 1+3; 1+5; 1+7; 1+8; 1+18; 1+19; 1+20; 1+26; 1+28; 1+40; 2+2; 2+4; 2+5; 2+12; 2+13; 2+17; 2+28; 2+29; 2+66; 2+71; 3+3; 3+5; 3+7; 3+8; 3+19; 3+20; 3+28; 3+40; 4+4; 4+5; 4+12; 4+13; 4+17; 4+28; 4+29; 4+66; 4+71; 5+5; 5+7; 5+30; 5+40; 5+66; 7+7; 7+8; 7+20; 7+28; 8+8; 8+38; 8+40; 8+41; 12+30; 2+66; 13+66; 20+38; 25+25; 25+26; 26+41; 29+30; 29+66; 38+38; 40+40; 41+41; 66+66; 66+71
LTE Cat. DL: Cat.7 300 Mbps (Maximum)
LTE Cat. UL: Cat.13 150 Mbps (Maximum)
4G Antennas: 2 External 4G LTE Antennas
Wi-Fi Specifications
Wi-Fi: 802.11 a/b/g/n/ac, 2*2 MU-MIMO
Wi-Fi Antenna: 4 x External Wi-Fi Antennas
Wi-Fi Speed: 300 Mbps (2.4GHz), 866 Mbps (5GHz)
Connections: 32
Distance: Up to 50m outdoor
Ethernet Specifications
Ethernet Ports: 1 x RJ45 WAN Port | 4 x RJ45 LAN Ports
Ethernet Speed: 10/100/1000/2500 Mbps
Software Features
OS: Linux 3.1.0
Networking:
   Routing, AP, Wireless Bridge, Wired Bridge
   NAT, NAPT and ALG
   Port Forwarding (Ethernet WAN only), Open port, DMZ
   Port filtering, IP filtering, MAC filtering and URL filtering
   QOS Flow Control
   Static Route
   Denial of Service (DoS) protection
   Flexible and secure SPI Firewall
WAN: Support for PPPoE, Static IP, DHCP, IPv6 Support
LAN: Support for DHCP
Wi-Fi:
   Switching on and off Wi-Fi AP
   Modifying Wi-Fi SSID
   Modifying encryption mode and password
4G Modem:
   Physical SIM / vSIM
   SignalScan for vSIM
   VPN: PPTP, L2TP VPN
System Function:
   Restart
   Restore factory settings
   DDNS (Ethernet WAN only)
   SNTP Date/time update from Internet Time Server
   TR-069 (Ethernet WAN only)
   Logs and statistics
   WEB GUI
   USSD
   WPS
   Standby Mode
   Captive Portal
